JZ AD2 Two Drop Kit Dual Payload Delivery System
The JZ AD2 Two Drop Kit is a lightweight, all alloy dual delivery system designed for DJI Matrice 4 and Matrice 4D series drones. Using the E-Port Lite interface for power and communication, it integrates seamlessly with DJI Pilot 2 and the remote controller, delivering precise, flexible, and reliable payload deployment for professional operations.
Weighing only 43 grams, the JZ AD2 minimizes impact on flight performance while providing two independent mounting positions for controlled payload release. It can operate simultaneously with accessories such as megaphones and searchlights, and supports connection to an external PTZ laser assisted guidance module for enhanced delivery accuracy.
Applications
- Precision payload delivery
- Search & rescue support
- Public safety operations
- Inspection and field logistics
Key Features
Mount Detection
- Dual mounting positions
- DJI Pilot 2 displays the mounting status of each position in real time
Arbitrary Delivery
- Independent payload release for each mount
- Controlled directly through DJI Pilot 2
- No fixed release order, click and deploy as needed
PTZ Laser Support
- Compatible with external PTZ laser-assisted guidance modules
- Supports use with M4T / M4TD for precise targeting
Lightweight All-Alloy Design
- All-alloy structural construction
- Strong, durable, and built for professional use
- Total weight of only 43 grams
JZ AD2 Two Drop Kit Dual Payload Delivery System
The JZ AD2 Two Drop Kit is a lightweight, all alloy dual delivery system designed for DJI Matrice 4 and Matrice 4D series drones. Using the E-Port Lite interface for power and communication, it integrates seamlessly with DJI Pilot 2 and the remote controller, delivering precise, flexible, and reliable payload deployment for professional operations.
Weighing only 43 grams, the JZ AD2 minimizes impact on flight performance while providing two independent mounting positions for controlled payload release. It can operate simultaneously with accessories such as megaphones and searchlights, and supports connection to an external PTZ laser assisted guidance module for enhanced delivery accuracy.
Applications
- Precision payload delivery
- Search & rescue support
- Public safety operations
- Inspection and field logistics
Key Features
Mount Detection
- Dual mounting positions
- DJI Pilot 2 displays the mounting status of each position in real time
Arbitrary Delivery
- Independent payload release for each mount
- Controlled directly through DJI Pilot 2
- No fixed release order, click and deploy as needed
PTZ Laser Support
- Compatible with external PTZ laser-assisted guidance modules
- Supports use with M4T / M4TD for precise targeting
Lightweight All-Alloy Design
- All-alloy structural construction
- Strong, durable, and built for professional use
- Total weight of only 43 grams
| Product Model | JA AD2 |
| Electrical interface | DJI SDK Interface |
| Size | 42x 60x21 mm |
| Rated power | 10 w |
| Weight | 43g |
| Supported Models | Matrice 4E/4T Matrice 4D/4TD （With bracket） |
| Number of mounts | 2 |
| Single hook loading weight | Maximum 1kg, actual load is subject to aircraft load |
| Total load weight | Maximum 2kg, actual load is subject to aircraft load |
| Delivery method | Single-point delivery, one-click delivery |
| Control method | DJI Pilot 2 |
| Installation | Screw quick release |
| Protection level | IP44 |
| Features | PSDK control Mount position detection Single-point delivery One-button full delivery No power-on required for mounting External laser aiming possible |
| Operating temperature | -10℃ to +50℃ / 14 °F to 122 °F |
| Storage temperature | -20℃ to +60℃ / −4 °F to 140 °F |
Matrice 4 Enterprise
Matrice 4 Thermal
*Matrice 4D - with bracket
*Matrice 4TD - with bracket
* Cannot be used in Dock 3s - only standalone manually flown aircraft.
